Phocos PWM Charge Controllers

PWM = Puls-Wide-Modulation Charging Method


PVshop.eu | EBORX Sp. z o.o. Authorized PHOCOS Distributor


Sizing the charge controllers in PV off-grid systems:



  • Do not exceed the controller allowed max current and voltage A/V defined as Isc/Voc.
  • In PWM controller max allowed voltage results from battery.min.voltage +30V (eg in 12Vdc systems: ~10Vmin.bat + 30V = 40V max).
  • In MPPT controller the absolute max allowed voltage is defined in the datasheet.
  • The real occuring current and voltage of the panel depends on temperature coefficient of the panel. Calculate additional 25% (A/V) which may occur under low temperature, as safety buffer (eg if panel Isc 8A, calculate +25% = 10A which may occur).
  • To choose the correct battery capacity, multiply the controller nominal current x10 (eg for an 10A controller choose 100Ah battery).
  • Always check the controller's datasheet and manual for individual parameters.


PV Calculator
Diagrams    Guide PV Off-Grid Systems

PWM

Sort by: ▲ Product name | Net Price
Phocos CM 4A Charge Controller (12V)

Solar charge controller for 12V PV solar systems

Available models: Phocos CM04

Nominal voltage: 12V

Panel max current: 4A (Isc)

Panel max voltage: 30V (Voc)

Charging method: PWM

Monitoring: LED

Function: protection against overcharge of battery

Net Price: 15,20 €
pcs.
Phocos CA 06 Charge Controller (12V)

Solar charge controller for 12V PV solar systems

Available models: Phocos CA06

Nominal voltage: 12V

Panel max current: 6 (Isc)

Panel max voltage: 40V (Voc)

Charging method: PWM

Monitoring: three LED's

Positive grounding possible

Function: protection against overcharge- and deep-discharge of battery

Net Price: 21,11 €
pcs.
Phocos CA 10A Charge Controller (12V)

Solar charge controller for 12V PV solar systems

Available models: Phocos CA10

Nominal voltage: 12V

Panel max current: 10A (Isc)

Panel max voltage: 40V (Voc)

Charging method: PWM

Monitoring: three LED's

Positive grounding possible

Function: protection against overcharge- and deep-discharge of battery

Net Price: 27,23 €
pcs.
Phocos CML10 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 3-stage

Monitoring: three LED

Function: protection against overcharge- and deep-discharge of battery

Net Price: 40,51 €
pcs.
Phocos CML15 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 15A (Isc)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 3-stage

Monitoring: three LED

Function: protection against overcharge- and deep-discharge of battery

Net Price: 59,02 €
pcs.
Phocos CML20 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Available models: Phocos CML 10/15/20

Nominal voltage: 12/24V (autodetection)

Panel max current: 10/15/20A (Isc)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 3-stage

Monitoring: three LED

Function: protection against overcharge- and deep-discharge of battery

Net Price: 65,58 €
pcs.
Phocos CMLsolid 30

Four-Stage PWM Solar Charge Controller for 12/24V PV systems

Nominal voltage: 12/24V (autodetection)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM

Charger for external devices via USB port

Battery state-of-charge indication via 3 LEDs

Load disconnect pre-warning via acoustic signal

Aluminuim housing



Net Price: 93,20 €
pcs.
  • new
Phocos CMLup 10

Solar Charge Controllers with Mobile Phone Charging Capability

Nominal voltage: 12/24V (autodetection)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM

Monitoring: three LED

Function: USB port for charging mobile phones or small music players

Net Price: 44,64 €
pcs.
  • new
Phocos CMLup 20

Solar Charge Controllers with Mobile Phone Charging Capability

Nominal voltage: 12/24V (autodetection)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM

Monitoring: three LED

Function: USB port for charging mobile phones or small music players

Net Price: 58,44 €
pcs.
  • new
Phocos CX10 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year)



Net Price: 51,62 €
pcs.
Phocos CX20 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year)



Net Price: 81,99 €
pcs.
Phocos CX40 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 40A (Isc)

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year)



Net Price: 127,40 €
pcs.
Phocos CX20-48V Charge Controller (24/48V)

Solar charge controller for 24/48V PV solar systems

Nominal voltage: 24/48V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 50/95V (Voc) in 24/48V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year)

Net Price: 125,13 €
pcs.
Phocos CX40-48V Charge Controller (24/48V)

Solar charge controller for 24/48V PV solar systems

Nominal voltage: 24/48V (autodetection)

Panel max current: 40A (Isc)

Panel max voltage: 50/95V (Voc) in 24/48V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year)

Net Price: 184,47 €
pcs.
Phocos CXup10 Charge Controller (12/24V)

Solar charge controller for 12/24V PV solar systems

Nominal voltage: 12/24V (autodetection)

Max charge/load current: 10A

Panel max voltage: 30/50V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LC-Display

Function: rogrammable nightlight function, USB charging port, data logger information can also be exported, load status indication,

touch keys ensure long lasting operation



Net Price: 70,83 €
pcs.
  • new
Phocos CXN10 Charge Controller (12/24V)

Solar charge controller for 12/24V negative grounded systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 30/50V (Voc) for 12/24V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year), negative grounding (N-series)

Net Price: 62,82 €
pcs.
Phocos CXN20 Charge Controller (12/24V)

Solar charge controller for 12/24V negative grounded systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 30/50V (Voc) for 12/24V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year), negative grounding (N-series)

Net Price: 94,58 €
pcs.
Phocos CXN40 Charge Controller (12/24V)

Solar charge controller for 12/24V negative grounded systems

Nominal voltage: 12/24V (autodetection)

Panel max current: 40A (Isc)

Panel max voltage: 30/50V (Voc) for 12/24V systems

Charging method: PWM 4-stage

Monitoring: LCD-Display

Function: protection against overcharge- and deep-discharge of battery, datalogger (one year), negative grounding (N-series)

Net Price: 139,87 €
pcs.
Phocos CXNsolid 50 Charge Controller (12/24/48V)

Solar charge controller for 12/24/48V negative grounded systems

Nominal voltage: 12/24/48V (autodetection)

Max charge/loads current: 50A (Isc)

Panel max voltage: 30/50/100V (Voc) for 12/24/48V systems

Charging method: PWM 4-stage

Monitoring: LC-Display

Aluminium housing

Function: deep-discharge protection of battery, data logger-2 years, external temperature sensor, negative grounding (N-series)

Net Price: 289,12 €
pcs.
  • new
Phocos CXNup20-2B Dual Battery Solar Charge Controller with LCD

Dual Battery Solar Charge Controller with LCD

Nominal voltage: 12/24V (autodetection)

Max charge current: 20A (Isc)

Panel max voltage: 30/50V (Voc) for 12/24V systems

Charging method: PWM 4-stage

Monitoring: LC-Display

Function: deep-discharge protection of battery, data logger-2 years, external temperature sensor, negative pole grounded

Net Price: 113,54 €
pcs.
  • new
Phocos ECO 10 Charge Controller (12V)

Solar charge controller for 12V

Nominal voltage: 12V

Max charge/loads current: 10A

Panel max voltage: 30V (Voc) for 12V systems

Charging method: PWM

Three LED indications: Charge Status, SOC, LVD, Overload/Short Circuit

Function: protected against: panel surge voltage, wrong polarity (panel or battery), overload and short circuit at load

Net Price: 23,46 €
pcs.
  • new
Phocos Ecoterm 14 Charge Controller (12V)

Solar charge controller for 12V

Nominal voltage: 12V

Max charge/loads current: 14A

Panel max voltage: 30V (Voc) for 12V systems

Charging method: PWM

Three LED indications: Charge Status, SOC, LVD, Overload/Short Circuit

Function: protected against: panel surge voltage, wrong polarity (panel or battery), overload and short circuit at load

Net Price: 31,28 €
pcs.
  • new
Phocos ECO-T-MPPT 85/16 - Compatible with 60 cell PV modules

MPPT Solar charge controller for 12/24V

Max charge/loads current: 16A

Panel max voltage: 85V (Voc)

Panel min voltage: 17/34V

Charging method: PWM

Auto-protect function: voltage disconnect increase reliability

Compatible with 60 cell PV modules: 60 cell modules can now also be used in 12 and
24 V DC systems

Net Price: 94,16 €
pcs.
  • new
Phocos CIS05 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller

Loads: single load (dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 5A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, positive-grounding possible (on plus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for one load

Net Price: 36,72 €
pcs.
Phocos CIS10 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller

Loads: single load (dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, positive-grounding possible (on plus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for one load

Net Price: 53,05 €
pcs.
Phocos CIS20 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller

Loads: single load (dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, positive-grounding possible (on plus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for one load

Net Price: 76,50 €
pcs.
Phocos CIS05-2L Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller

Loads: dual loads (not dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 5A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, positive-grounding possible (on plus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for two loads (2L series)

Net Price: 42,84 €
pcs.
Phocos CIS10-2L Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller

Loads: dual loads (not dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, positive-grounding possible (on plus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for two loads (2L series)

Net Price: 61,10 €
pcs.
Phocos CIS20-2L Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller

Loads: dual loads (not dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, positive-grounding possible (on plus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for two loads (2L series)

Net Price: 87,72 €
pcs.
Phocos CIS-N-05 Waterproof Controller (12/24V)

Waterproof (IP68) negative grounded charge controller

Loads: single load (dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 5A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, negative-grounding (on minus line)

Function: protection against overcharge- and deep-discharge of battery

Net Price: 78,54 €
pcs.
Phocos CIS-N-10 Waterproof Controller (12/24V)

Waterproof (IP68) negative grounded charge controller

Loads: single load (dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, negative-grounding (on minus line)

Function: protection against overcharge- and deep-discharge of battery

Net Price: 90,88 €
pcs.
Phocos CIS-N-20 Waterproof Controller (12/24V)

Waterproof (IP68) negative grounded charge controller

Loads: single load (dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, negative-grounding (on minus line)

Function: protection against overcharge- and deep-discharge of battery

Net Price: 119,34 €
pcs.
Phocos CIS-N-05-2L Waterproof Controller (12/24V)

Waterproof (IP68) negative grounded charge controller

Loads: dual loads (not dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 5A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, negative-grounding (on minus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for one or two loads (2L series)

Net Price: 86,70 €
pcs.
Phocos CIS-N-10-2L Waterproof Controller (12/24V)

Waterproof (IP68) negative grounded charge controller

Loads: dual loads (not dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 10A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, negative-grounding (on minus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for one or two loads (2L series)

Net Price: 100,98 €
pcs.
Phocos CIS-N-20-2L Waterproof Controller (12/24V)

Waterproof (IP68) negative grounded charge controller

Loads: dual loads (not dimmable)

Nominal voltage: 12/24V (autodetection)

Panel max current: 20A (Isc)

Panel max voltage: 42/52V (Voc) in 12/24V systems

Charging method: PWM 4-stage

Monitoring: LED's, negative-grounding (on minus line)

Function: protection against overcharge- and deep-discharge of battery, programmable for one or two loads (2L series)

Net Price: 128,52 €
pcs.
Phocos CIS-N-LED-350 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller with LED driver

Combines three functions in one: charge controller + flexible timer + LED drivers

Loads: single load (dimmable)

Nominal voltage: 12/24V

Charging method: PWM 4-stage

Monitoring: LED's, negative grounded

Function: protection against overcharge- and deep-discharge of battery, LED-driver integrated

Net Price: 88,56 €
pcs.
  • new
Phocos CIS-N-LED-600 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller with LED driver

Combines three functions in one: charge controller + flexible timer + LED drivers

Loads: single load (dimmable)

Nominal voltage: 12/24V

Charging method: PWM 4-stage

Monitoring: LED's, negative grounded

Function: protection against overcharge- and deep-discharge of battery, LED-driver integrated

Net Price: 88,56 €
pcs.
  • new
Phocos CIS-N-LED-700 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller with LED driver

Combines three functions in one: charge controller + flexible timer + LED drivers

Loads: single load (dimmable)

Nominal voltage: 12/24V

Charging method: PWM 4-stage

Monitoring: LED's, negative grounded

Function: protection against overcharge- and deep-discharge of battery, LED-driver integrated

Net Price: 88,56 €
pcs.
  • new
Phocos CIS-N-LED-1050 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller with LED driver

Combines three functions in one: charge controller + flexible timer + LED drivers

Loads: single load (dimmable)

Nominal voltage: 12/24V

Charging method: PWM 4-stage

Monitoring: LED's, negative grounded

Function: protection against overcharge- and deep-discharge of battery, LED-driver integrated

Net Price: 95,27 €
pcs.
  • new
Phocos CIS-N-LED-1400 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller with LED driver

Combines three functions in one: charge controller + flexible timer + LED drivers

Loads: single load (dimmable)

Nominal voltage: 12/24V

Charging method: PWM 4-stage

Monitoring: LED's, negative grounded

Function: protection against overcharge- and deep-discharge of battery, LED-driver integrated

Net Price: 95,27 €
pcs.
  • new
Phocos CIS-N-LED-2800 Waterproof Controller (12/24V)

Waterproof (IP68) PV solar charge controller with LED driver

Combines three functions in one: charge controller + flexible timer + LED drivers

Loads: single load (dimmable)

Nominal voltage: 12/24V

Charging method: PWM 4-stage

Monitoring: LED's, negative grounded

Function: protection against overcharge- and deep-discharge of battery, LED-driver integrated

Net Price: 95,27 €
pcs.
  • new
Phocos MPS45 | Modular Power Switch for 12/24/48V

MPS solar charge or load controller (IP22)

Component within Modular Power Management (MPM)

Nominal voltage: 12/24/48V

Panel max current: 45A (Isc)

Load max current: 45A

Panel max voltage: 90V (Voc)

Possible flexible grounding (on minus or plus line)

Function: PWM charge or load controller (not both simultaneously !).

Net Price: 217,72 €
pcs.
Phocos MPS80 | Modular Power Switch for 12/24/48V

MPS solar charge or load controller (IP22)

Component within Modular Power Management (MPM)

Nominal voltage: 12/24/48V

Panel max current: 80A (Isc)

Load max current: 480A

Panel max voltage: 90V (Voc)

Possible flexible grounding (on minus or plus line)

Function: PWM charge or load controller (not both simultaneously !).

Net Price: 285,54 €
pcs.

eborx - solar systems
Solar for Kids our blog eborx on facebook eborx on youtube
Sklep internetowy Shoper.pl
